SoketAM4
Yonga SetiAMD X570
İşlemciSupports 2nd and 3rd Gen AMD Ryzen™ / Ryzen™ with Radeon™ Vega Graphics and 2nd Gen AMD Ryzen™ with Radeon™ Graphics Desktop Processors for Socket AM4
Bellek4x DDR4 memory slots, support up to 128GB 3rd Gen AMD Ryzen™ Processors support DDR4 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200 Mhz by JEDEC, and 2667/ 2800 /2933 /3000 /3066 /3200 /3466 /3600/ 3733 /3866 /4000 /4133 /4266 /4400 Mhz by A-XMP OC MODE; nd Gen AMD Ryzen™ Processors, 1st and 2nd Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors support DDR4 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200 Mhz by JEDEC, and 2667 /2800 / 2933 /3000 /3066 /3200 /3466 Mhz by A-XMP OC MODE; Dual channel memory architecture; Supports non-ECC UDIMM memory; Supports ECC UDIMM memory (non-ECC mode); Supports un-buffered memory
Grafik1x HDMI 1.4 port, maksimum çözünürlük 4096x2160 @24Hz
Genişletme Yuvaları
1x PCIe 4.0/3.0 x16 slot (PCI_E1) / 1x PCIe 4.0/ 3.0 x16 slot (PCI_E3, supports x4 mode) / 3x PCIe 3.0 x1SATA 36 x SATA 6Gb/s
M.2 Slot2
RAID0/1/10
LAN1x Realtek 8111H Gigabit LAN Controller
SesRealtek ALC1220 Codec 7.1-Channel High Definition Audio
Multi-GPU2-Way AMD CrossFire Technology
İşletim SistemiWindows 10, 64-bit
Form FaktörüATX Form Faktör / 12 in. x 9.6 in. (30.4 cm x 24.3 cm)
